Ultimate Image Guide: The Manufacturing process of Hydraulic Cylinders.
Hydraulic cylinders are widely used in engineering machinery, machine tool equipment, automobile manufacturing, metallurgy and mining, aerospace and other fields. So, how are hydraulic cylinders produced? 1. Preliminary preparation 1.1 Design Hydraulic components and sealing components have different requirements in terms of dimensional tolerance, surface roughness, shape and position tolerance, etc. Therefore, the geometric accuracy of each component must be ensured and the correct seal must be selected during design. 1.2 Steel material selection: Commonly used steels are #20 steel, #45 steel, and 40Cr. The hardness of the steel is different, the applicable working conditions are different, and the price is also different, so comprehensive consideration is required. 2.The Production Processing 2.1 Cylinder body Generally, seamless steel pipes without bending or deformation are selected. In order to ensure its good toughness and plasticity, it needs to go through a series of processing. Cut the steel pipe into required length. Threads are machined on the inner walls of both ends of the steel pipe. Drill oil holes at appropriate locations and weld oil pipes. During the production of hydraulic cylinders, many processes such as cylinder barrels and piston rods require welding. High-precision welding machines can ensure welding quality. Scraping and polishing:
19 reasons for hydraulic cylinder creep and corresponding troubleshooting methods
The hydraulic cylinder often has a jumping and stopping movement state during operation, which we call creeping phenomenon. This phenomenon is especially easy to occur at low speed, which is also one of the main faults of hydraulic cylinder.To solve the problem of hydraulic cylinder creep, we must study the cause of this phenomenon. After summarizing, we found that the cause for hydraulic cylinder creep not only have something to do with the hydraulic cylinder itself and also related to other factors outside the cylinder. Let’s talk about it today. Internal causes of hydraulic cylinder creep failure ① There is residual air in the cylinder, and the working medium forms an elastic body. Troubleshooting method: Fully exhaust the air; check whether the diameter of the hydraulic pump suction pipe is too small, and the suction pipe joint should be well sealed to prevent the pump from sucking air. ② The sealing friction is too large. Troubleshooting method: The piston rod and the guide sleeve are matched with H8/f8, and the depth and width of the sealing ring groove are strictly made according to the dimensional tolerance; if a V-shaped sealing ring is used, adjust the sealing friction to a moderate degree. ③ The sliding parts
North-South Commuter Railway Extension Project 1569 Ton Pile Load Testing
Project Images Project Introduction The North-South Commuter Railway, also known as the Clark–Calamba Railway, is a 147-kilometer urban rail transit system under construction on the island of Luzon, Philippines, primarily in the Greater Manila Area. The project will utilize the Japanese railway system that uses energy-efficient and reliable trains. RIVERLAKE supplied a pile load testing system consisting of 2 units of 1000-ton hydraulic cylinders and 1 unit PLC-controlled electric hydraulic power unit. The system will perform pile load testing work up to 1569 tons in the NSCR Extension Project. RIVERLAKE PLC controlled hydraulic jacking system is designed for pile load tests up to 2000 tons where the load is to be applied in different stages and displayed accurately in real-time. The plc pile load test jacking system provides 6 default tonnage options, user can preset the loading tonnage and holding period of time for each option. During pile load test operation, the whole process is run automatically, just select one of the preset tonnages and press the auto-run button. the hydraulic jack will raise to its full stroke, upon reaching the preset load, the jacking system will stop automatically and hold the pressure for the preset period of time. The
Transformer Relocation In South Africa
Project Images Project Introduction Taizhou Chuanhu Hydraulic Machinery Co., Ltd delivered 6 double-acting hydraulic cylinders and a petrol-driven hydraulic power unit for the skidding and sliding systems. The Power Pack and hydraulic cylinders are used for electric transformer relocation.
