Customer Visit RIVERLAKE for Hydraulic Cylinder Quality Inspection

The hydraulic cylinder often has a jumping and stopping movement state during operation, which we call creeping phenomenon. This phenomenon is especially easy to occur at low speed, which is also one of the main faults of hydraulic cylinder.To solve the problem of hydraulic cylinder creep, we must study the cause of this phenomenon. After summarizing, we found that the cause for hydraulic cylinder creep not only have something to do with the hydraulic cylinder itself and also related to other factors outside the cylinder. Let’s talk about it today. Internal causes of hydraulic cylinder creep failure ① There is residual air in the cylinder, and the working medium forms an elastic body. Troubleshooting method: Fully exhaust the air; check whether the diameter of the hydraulic pump suction pipe is too small, and the suction pipe joint should be well sealed to prevent the pump from sucking air. ② The sealing friction is too large. Troubleshooting method: The piston rod and the guide sleeve are matched with H8/f8, and the depth and width of the sealing ring groove are strictly made according to the dimensional tolerance; if a V-shaped sealing ring is used, adjust the sealing friction to a moderate degree. ③ The sliding parts

In hydraulic systems, hydraulic cylinders are widely used in a variety of scenarios such as heavy lifting operations, propulsion operations, and driving operations. In these systems, the synchronous operation of multiple hydraulic cylinders is an important part of ensuring the efficient and safe operation of the equipment. The synchronization of hydraulic cylinders can not only improve the efficiency of operations, but also avoid equipment damage caused by inconsistent movement. This article will explore in depth the principles of the synchronous movement of multiple hydraulic cylinders, common synchronization methods, technical challenges, and precautions during operation. 1. Working principle of hydraulic cylinder synchronization Hydraulic cylinder synchronization means that multiple cylinders extend or retract at the same speed and force at the same time. The core lies in the uniform distribution of hydraulic fluid and the precise control of pressure. The realization of synchronous operation depends on the following key factors: Fluid dynamics: The basic principle of the hydraulic system is to use the incompressibility of the liquid to convert pressure into power. The synchronous movement of the cylinder is achieved by controlling the direction and flow of the liquid flow. Load balancing: When multiple hydraulic cylinders share the load, ensure that each

Project Images Project Introduction 50-ton low height pancake hydraulic cylinders used in auger boring steerable rock system.Steerable head designed for boring through sand or soft rock with real-time steering adjustments made out of the pit with a hydraulic control system. The Steerable Rock System (SRS) is the auger boring market’s first steerable head designed to navigate not only solid rock but difficult fractured rock conditions as well. Engineered to operate in rock up to 25,000 psi, the SRS allows operators to keep bores online and grade even in the toughest ground conditions for an on-grade bore. On the drilling head, there is peace’s of small round pipe, that’s where the cylinders sit. There are 4 pcs 50-ton pancake hydraulic cylinders on each side(top, bottom, right, and left) of the steerable head for a total of 16pcs, it works when it’s drilling horizontally underground we use the cylinders to navigate the drilling head.

Project Images Project Introduction Hydraulic Testing Projects With China National Offshore Oil Corporation
