Description
Model: HE84TW
Series: HETW
Product Lines: Industrial Tools
- Ultra-Quiet Brushless Motor (75 dB): Maintenance-free operation with minimal worksite disruption.
- Lightweight Aluminum Oil Tank: Superior heat dissipation and easy portability.
- Lockable Precision Pressure Regulator: Ensures exact pressure control for consistent torque accuracy.
- Dual-Stage Pump: Rapid low-pressure filling and seamless transition to high-pressure output.
- 6m Low-Voltage Control Handle: Safe remote operation from hazardous zones.
- High-Efficiency Air Cooling: Sustains performance during extended continuous use.
- Visual Oil Level Indicator: Real-time fluid monitoring for proactive maintenance.
- Motor Overload Protection: Guards against electrical faults and overheating.
- 3m Industrial Power Cord: Ready for challenging worksite conditions.
- All-in-One Protective Frame + Cable Reel: Integrated storage and damage resistance.
- Tool-Free Pressure Gauge: Quick maintenance without rotation or tools.
Think Safety
Manufacturer’s rating of load and stroke are maximum safe limits. Good practice encourages using only 80% of these ratings!
CE Certification
Specifications
| Max Working Pressure(bar) | 700 |
| High-Pressure Oil Flow (L/min) | 2.3 |
| Low-Pressure Oil Flow (L/min) | 12 |
| Motor Power(KW) | 4 |
| Oil Capacity(L) | 40 |
| Voltage | 380VAC |
| Weight Without Oil(Kg) | 108 |
Series Comparison
| Model | Max Working Pressure(MPa) | High Pressure Oil Flow (L/min) | Low Pressure Oil Flow (L/min) | Motor Power(KW) | Oil Capacity(L) | Voltage | Torque Wrench Numbers | Dimesnions(mm) | Weight Without Oil(Kg) |
|---|---|---|---|---|---|---|---|---|---|
| HE7TW10-C2 | 70 | 1.5 | 12 | 2.2 | 10 | 380VAC | 2 | 468*392*574 | 50 |
| HE7TW10-C4 | 70 | 1.5 | 12 | 2.2 | 10 | 380VAC | 4 | 468*392*574 | 52 |
| HE84TW40-C2 | 70 | 2.3 | 12 | 4 | 40 | 380VAC | 2 | 630*480*1000 | 108 |
| HE84TW40-C4 | 70 | 2.3 | 12 | 4 | 40 | 380VAC | 4 | 630*480*1000 | 110 |
