Description
Product Lines: Industrial Tools
- PLC Touchscreen Control: Fully automated pressure programs with intuitive user interface.
- One-Touch Pressure Holding: Set target pressure (±0.5MPa accuracy); the system auto-adjusts to maintain it indefinitely.
- Direct-Drive Pressurization Pump: Eliminates intensifiers for superior stability and extended service life.
- Emergency Manual Pressure Release: Fail-safe mechanical dump valve (functions even during power loss).
- Active Air-Cooled Cooling: Minimizes oil temperature rise during 24/7 operation.
- Real-Time Pressure/Time Graphing: Records and displays curves for quality assurance and compliance.
- External Adjustable Pressure Limiter: Secondary overpressure protection.
- Smart Safety Alarms: Pressure rise timeout + sensor signal loss alerts.
- Multi-Unit Display (MPa/BAR/PSI/KN): Global unit flexibility.
- Oil Level/Temperature Sensors: Live monitoring with low-fluid/high-temp warnings.
Think Safety
Manufacturer’s rating of load and stroke are maximum safe limits. Good practice encourages using only 80% of these ratings!
Image Gallery
CE Certification
Operation Steps
- Set the target pressure on the screen
- Click the start button
- The hydraulic pump automatically increases the pressure, reaches the target pressure, and gives a status indication
- Perform pre-tightening, disassembly and assembly operations
- When the pressure drops to the set accuracy value, the servo starts the pressure replenishment operation, and the pressure rises to the target value again
- When the work is completed, click the pressure relief button and the pressure is automatically unloaded
Specifications
| Model | Rated Working Pressure(Bar) | High Pressure Flow Rate(L/min) | Low Pressure Flow Rate(L/min) | Usable Oil(L) | Power(KW) | Dimensions(mm） | Weight(Kg) |
|---|---|---|---|---|---|---|---|
| ESP1500 | 1500 | 0.3 | 2.5 | 20 | 1.5 | 520*375*940 | 55 |
| ESP2500 | 2500 | 0.2 | 2.5 | 20 | 1.5 | 520*375*940 | 55 |
