Description
Model: RRH-606
Series: RRH
Product Lines: Industrial Tools
- The hollow plunger design allows for both pull and pushes forces
- Double-acting for fast retraction
- Nickel-plated, floating center tube to increase product durability.
- Baked enamel finish for increased corrosion resistance
- Collar threads for easy fixturing
- Relief valves prevent damage in case of over-pressurization
- Plunger wiper reduces contamination, extending cylinder life
- Hardened and chromed piston reduces wear and corrosion
- Hardened alloy steel guide ring eliminates over travel and provides support to reduce wear from off-center loads
- High strength composite bearing provides support for off-center loads without damaging the cylinder walls
- An Industrial U-cup style seal prevents costly leaks
Think Safety
Manufacturer’s rating of load and stroke are maximum safe limits. Good practice encourages using only 80% of these ratings!
Specifications
Maximum Operating Pressure (bar) | 700 |
Capacity Class (tonnage) | 60 |
Maximum Cylinder Capacity Advance (kN) | 576 |
Maximum Cylinder Capacity Retract (kN) | 380 |
Stroke (mm) | 166 |
Collapsed Height A (mm) | 323 |
Extended Height B (mm) | 489 |
Return Type | Double-Acting, Hydraulic Return |
Plunger Type | Hollow |
Material | CR40 |
Cylinder Effective Area Advance (cm2) | 87.4 |
Cylinder Effective Area Retract (cm2) | 56.2 |
Oil Capacity Advance (cm3) | 1451 |
Oil Capacity Retract (cm3) | 891 |
Surface Treatment | Baked enamel finish |
Coupler | 3/8NPT-18 |
Weight (kg) | 35 |
Dimensions
Collapsed Height/mm(A) | 323.0 |
Extended Height/mm(B) | 489.0 |
Outside Dia/mm(D) | 159.0 |
Cylinder Bore Dia/mm(E) | 123.9 |
Plunger Dia/mm(F) | 92.0 |
Base To Advance Port/mm(H) | 31.0 |
Top To Retract Port/mm(I) | 66.0 |
Saddle Dia/mm(J) | 91.0 |
Saddle Protri. From Plgr./mm(K) | 12.0 |
Thread(O) | 2 3/4”-16 |
Plunger Thread Length/mm(P) | 19.0 |
Collar Thread(W) | 6.1/4″ – 12 UNC |
Collar Thread Length/mm(X) | 48.0 |
Base Mounting Hole Bolt Cicle(U) | 130.0 |
Base Mounting Hole Thread(V) | 1/2”-13 |
Base Mounting Hole Thread Depth/mm(Z) | 14.0 |
Center Hole Dia/mm(Y) | 53.8 |
Series Comparison
Model Number | Capacity/Ton | Stroke/mm | Push Max Cylinder Capacity/KN | Pull Max Cylinder Capacity/KN | Push Cylinder Effective Area/cm2 | Pull Cylinder Effective Area/cm2 | Push Oil Capacity/cm3 | Pull Oil Capacity/cm3 | Collapsed Height/mm(A) | Extended Height/mm(B) | Outside Dia/mm(D) | Cylinder Bore Dia/mm(E) | Plunger Dia/mm(F) | Base To Advance Port/mm(H) | Top To Retract Port/mm(I) | Saddle Dia/mm(J) | Saddle Protri. From Plgr./mm(K) | Thread(O) | Plunger Thread Length/mm(P) | Collar Thread(W) | Collar Thread Length/mm(X) | Base Mounting Hole Bolt Cicle(U) | Base Mounting Hole Thread(V) | Base Mounting Hole Thread Depth/mm(Z) | Center Hole Dia/mm(Y) | Weight/Kg |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
RRH-307 | 30.0 | 178.0 | 326.0 | 213.0 | 47.7 | 32.4 | 849.0 | 577.0 | 330.0 | 508.0 | 114.0 | 88.9 | 65.0 | 25.0 | 60.0 | 63.0 | 9.0 | 1 13/16” -16 | 22.0 | 4.1/2″ – 12 UN | 41.9 | 92.2 | 3/8”-16 | 15.7 | 33.3 | 21.0 |
RRH-3010 | 30.0 | 258.0 | 326.0 | 213.0 | 47.7 | 32.4 | 1231.0 | 836.0 | 431.0 | 689.0 | 114.0 | 88.9 | 65.0 | 25.0 | 60.0 | 63.0 | 9.0 | 1 13/16” -16 | 22.0 | 4.1/2″ – 12 UN | 41.9 | 92.2 | 3/8”-16 | 15.7 | 33.3 | 27.0 |
RRH-603 | 60.0 | 89.0 | 576.0 | 380.0 | 87.4 | 56.2 | 778.0 | 481.0 | 246.0 | 336.0 | 159.0 | 123.9 | 92.0 | 31.0 | 66.0 | 91.0 | 12.0 | 2 3/4”-16 | 19.0 | 6.1/4″ – 12 UNC | 48.0 | 130.0 | 1/2”-13 | 14.0 | 53.8 | 28.0 |
RRH-606 | 60.0 | 166.0 | 576.0 | 380.0 | 87.4 | 56.2 | 1451.0 | 891.0 | 323.0 | 489.0 | 159.0 | 123.9 | 92.0 | 31.0 | 66.0 | 91.0 | 12.0 | 2 3/4”-16 | 19.0 | 6.1/4″ – 12 UNC | 48.0 | 130.0 | 1/2”-13 | 14.0 | 53.8 | 35.0 |
RRH-6010 | 60.0 | 257.0 | 576.0 | 380.0 | 87.4 | 56.2 | 2246.0 | 1388.0 | 438.0 | 695.0 | 159.0 | 123.9 | 92.0 | 31.0 | 66.0 | 91.0 | 12.0 | 2 3/4”-16 | 25.0 | 6.1/4″ – 12 UNC | 48.0 | 130.0 | 1/2”-13 | 14.0 | 53.8 | 45.0 |
RRH-1001 | 95.0 | 38.0 | 931.0 | 612.0 | 135.2 | 87.1 | 514.0 | 331.0 | 165.0 | 203.0 | 212.0 | 165.1 | 127.0 | 38.0 | 44.0 | 126.0 | 12.0 | 4”-16 | 25.0 | – | – | 177.8 | 5/8”-11 | 19.0 | 79.2 | 33.0 |
RRH-1003 | 95.0 | 76.0 | 931.0 | 612.0 | 135.2 | 87.1 | 1027.0 | 662.0 | 254.0 | 330.0 | 212.0 | 165.1 | 127.0 | 38.0 | 85.0 | 126.0 | 12.0 | 4”-16 | 25.0 | 8.3/8″ – 12 UN | 59.9 | 177.8 | 5/8”-11 | 19.0 | 79.2 | 61.0 |
RRH-1006 | 95.0 | 153.0 | 931.0 | 612.0 | 135.2 | 87.1 | 2069.0 | 1333.0 | 342.0 | 495.0 | 212.0 | 165.1 | 127.0 | 38.0 | 85.0 | 126.0 | 12.0 | 4”-16 | 25.0 | 8.3/8″ – 12 UN | 59.9 | 177.8 | 5/8”-11 | 19.0 | 79.2 | 79.0 |
RRH-10010 | 95.0 | 257.0 | 931.0 | 612.0 | 135.2 | 87.1 | 3475.0 | 2239.0 | 460.0 | 717.0 | 212.0 | 165.1 | 127.0 | 38.0 | 85.0 | 126.0 | 12.0 | 4”-16 | 25.0 | 8.3/8″ – 12 UN | 59.9 | 177.8 | 5/8”-11 | 19.0 | 79.2 | 107.0 |
RRH-1508 | 145.0 | 203.0 | 1429.0 | 718.0 | 196.8 | 102.0 | 3995.0 | 2074.0 | 349.0 | 552.0 | 247.0 | 190.5 | 152.5 | 38.0 | 60.0 | 127.0 | 4.0 | 4 1/4”-12 | 25.0 | * | * | * | * | * | 79.2 | 111.0 |
