LWC16, 16 Ton, Vertical Lifting Wedge with Integrated Pump, 21 mm Lifting Height

Model: LWC16 | Product Line: Industrial Tools

• Integrated Hand Pump for Superior Maneuverability
  The self‑contained pump eliminates the need for external power sources or hoses. One operator can easily position and actuate the wedge, making it ideal for remote or cramped job sites where mobility is critical.

• Minimized Access Gap – Fits Where Others Can’t
  With an ultra‑thin nose profile, the LWC16 requires minimal insertion clearance. This design ensures accessibility even in the tightest gaps—between machinery bases, under structural components, or in narrow trench works.

• Red Travel Indicator for Visual Confidence
  A bright red indicator on the cylinder body provides a clear, at‑a‑glance reading of the extension stroke. Operators can precisely monitor lift height without guesswork, enhancing both safety and efficiency.

• Secure, Slippage‑Free Lifting & Lowering
  The wedge’s advanced friction‑grip geometry and controlled hydraulic flow ensure that the load remains firmly supported throughout the entire stroke. Lowering is equally smooth and stable, with no sudden drops or jerks.

• Single‑Acting, Spring‑Return Cylinder
  The cylinder operates on a single‑acting principle—pressure extends the wedge, while an internal mechanical spring provides automatic, positive retraction. This failsafe design eliminates the need for external return pressure and guarantees quick, repeatable reset cycles.

• Includes Safety Block SB2
  Every LWC16 comes with the SB2 safety block, a dedicated mechanical support that can be inserted under the lifted load as a secondary safeguard. This additional layer of protection allows maintenance personnel to work underneath with peace of mind.
