Description
Model: RT1817
Series: RT
Product Lines: Industrial Tools
- 3% side-load of full capacity.
- Double or triple wear bearings support lifting stages.
- Tilting saddles with 5 degrees of maximum tilt standard on all models.
- Certified lifting eyes for safe handling and positioning.
- Design Safety factor complies with ASME B30.1 & EN1494.
- Steel cylinder base for maximum strength.
Think Safety
Manufacturer’s rating of load and stroke are maximum safe limits. Good practice encourages using only 80% of these ratings!
CE Certification
Specifications
| Maximum Operating Pressure (bar) | 700 |
| Capacity Class (tonnage) | 17 |
| Stroke (mm) | 435 |
| Collapsed Height A (mm) | 345 |
| Extended Height B (mm) | 780 |
| Return Type | Single-Acting, load return |
| Material | CR40 |
| Oil Capacity Advance (cm3) | 3092 |
| Stage 1 Capacity (Tonnage) | 95 |
| Stage 1 Stroke S1 (mm) | 145 |
| Stage 2 Capacity (Tonnage) | 41 |
| Stage 2 Stroke S2 (mm) | 145 |
| Stage 3 Capacity (Tonnage) | 17 |
| Stage 3 Stroke S3 (mm) | 145 |
| Surface Treatment | Baked enamel finish |
| Coupler | 3/8NPT-18 |
| Weight (kg) | 40.3 |
Dimensions
| Collapsed Height/mm(A) | 345 |
| Extended Height/mm(B) | 780 |
| Outside Dia/mm(D) | 170 |
| Base To Advance Port/mm(H) | 27 |
| Standard Saddle Dia/mm(J) | 80 |
| Saddle Protri. From Plgr./mm(K) | 73 |
| Saddle Support Dia/mm(L) | 85 |
Series Comparison
| Model Number | Capacity/Ton | Stroke/mm | Oil Capacity/cm3 | Collapsed Height/mm(A) | Extended Height/mm(B) | 1st Stage Capacity/Ton | 1st Stage Stroke/mm | 2nd Stage Capacity/Ton | 2nd Stage Stroke/mm | 3rd Stage Capacity/Ton | 3rd Stage Stroke/mm | Outside Dia/mm(D) | Base To Advance Port/mm(H) | Standard Saddle Dia/mm(J) | Saddle Protri. From Plgr./mm(K) | Saddle Support Dia/mm(L) | Weight/Kg |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| RT1510 | 14 | 270 | 944 | 283 | 553 | 36 | 135 | 14 | 135 | * | * | 110 | 20 | 60 | 49 | 60 | 15.1 |
| RT1817 | 17 | 435 | 3092 | 345 | 780 | 95 | 145 | 41 | 145 | 17 | 145 | 170 | 27 | 80 | 73 | 85 | 40.3 |
| RT2111 | 20.2 | 300 | 1487 | 317 | 617 | 51 | 150 | 20 | 150 | * | * | 125 | 23 | 60 | 53 | 66 | 21.8 |
| RT2119 | 20.2 | 500 | 4661 | 395 | 895 | 126 | 170 | 51 | 170 | 20.2 | 160 | 200 | 34 | 90 | 83 | 100 | 67.3 |
| RT3311 | 31.5 | 300 | 2359 | 352 | 652 | 81 | 150 | 32 | 150 | * | * | 160 | 25 | 80 | 66 | 89 | 39.9 |
| RT3323 | 31.5 | 600 | 8816 | 476 | 1076 | 202 | 200 | 81 | 200 | 31.5 | 200 | 250 | 44 | 110 | 110 | 123 | 124 |
