Description

Model: SCS502E

Series: SCS

Product Lines: Industrial Tools

  • Optimum match of individual components
  • All sets are ready to use and include a single-acting cylinder, two-speed pump, 1.8 meters safety hose, calibrated gauge with gauge adaptor
  • RCS-Series, low height cylinder for maximum versatility

Think Safety

Manufacturer’s rating of load and stroke are maximum safe limits. Good practice encourages using only 80% of these ratings!

Specifications

Maximum Operating Pressure (bar)700
Capacity Class (tonnage)50
Stroke (mm)60
Collapsed Height (mm)122
Extended Height (mm)182
Return TypeSingle-Acting, Spring Return
Plunger TypeSolid
MaterialCR40
Pump ModelHE3005MV32RG
Cylinder ModelRCS502
Pressure Gauge & AdapterGA4 & GP10S
Hydraulic HoseHC-7206
