Description

Model: HCRL2508

Series: HCRL

Product Lines: Industrial Tools

  • Hydraulically controlled fast retraction
  • Lock nut provides mechanical load holding for a safe work environment
  • Designed to withstand up to 10% side-load of maximum capacity
  • An integrated tilt saddle allows up to 5 degrees of misalignment
  • Hardened surface resists side-loading and cyclic wear
  • Weather protected, inside and out
  • Replaceable bearings enclose the plunger external and internally for support
  • Certified lifting eyes, base mounting holes, and collar thread as standard
  • Stop-ring to prevent plunger blow-out
  • Low friction lock nut, spin easy, save time and effort
  • The HCRL-Series Cylinders are available up to 1000-ton capacity and 600mm stroke upon request. Contact RIVERLAKE for more information.

Think Safety

Manufacturer’s rating of load and stroke are maximum safe limits. Good practice encourages using only 80% of these ratings!

Specifications

Maximum Operating Pressure (bar)700
Capacity Class (tonnage)250
Stroke (mm)200
Collapsed Height A (mm)491
Extended Height B (mm)691
Return TypeDouble-Acting, Hydraulic Return
Plunger TypeSolid
MaterialCR40
Cylinder Effective Area (cm2)351.9
Oil Capacity Advance (cm3)7037
Oil Capacity Retract (cm3)707
Sideload Resistance of Maximum Capacity (percentage)10%
Surface TreatmentBaked enamel finish
Coupler3/8NPT-18
Weight (kg)224

Dimensions

Collapsed Height/mm(A)491
Extended Height/mm(B)691
Outside Dia/mm(D)290
Cylinder Bore Dia/mm(E)220
Plunger Dia/mm(F)Tr190X6
Base To Advance Port/mm(H1)71
Base To Retract Port/mm(H2)49
Saddle Dia/mm(J)160
Saddle Protr. /mm(K)15
Lock Nut Height/mm(S)55
Base Mounting Holes Bolt Circle/mm(U)245
Base Mounting Holes Thread(V)M12X1.75
Base Mounting Holes Min Thread Depth/mm(Z)22
Thread Size(W)M290X3
Thread Length/mm(X)85
HCRL Cylinder dim 1000

Series Comparison

Model NumberCapacity/TonStroke/mmCylinder Effective Area/cm2Push Oil Capacity/cm3Pill Oil Capacity/cm3Collapsed Height/mm(A)Extended Height/mm(B)Outside Dia/mm(D)Cylinder Bore Dia/mm(E)Plunger Dia/mm(F)Base To Advance Port/mm(H1)Base To Retract Port/mm(H2)Saddle Dia/mm(J)Saddle Protr. /mm(K)Lock Nut Height/mm(S)Base Mounting Holes Bolt Circle/mm(U)Base Mounting Holes Thread(V)Base Mounting Holes Min Thread Depth/mm(Z)Thread Size(W)Thread Length/mm(X)Weight/Kg
HCRL5065015068.4102586310460130100Tr90X44127771526105M12X1.7522M130X24230
HCRL5085020068.41367115377577130100Tr90X44127771526105M12X1.7522M130X24236
HCRL50105025068.41709143427677130100Tr90X44127771526105M12X1.7522M130X24240
HCRL50125030068.42051172477777130100Tr90X44127771526105M12X1.7522M130X24245
HCRL1006100150141.42121236346496185140TR120X605036771536150M12X1.7522M185X25764
HCRL1008100200141.42827314421621185140TR120X605036771536150M12X1.7522M185X25777
HCRL10010100250141.43534393471721185140TR120X605036771536150M12X1.7522M185X25785
HCRL10012100300141.44241471521821185140TR120X605036771536150M12X1.7522M185X25794
HCRL1506150150214.43216236359509222170Tr150X646321261345185M12X1.7522M222X37097
HCRL1508150200214.44288314434634222170Tr150X646321261345185M12X1.7522M222X370116
HCRL15010150250214.45360393484734222170Tr150X646321261345185M12X1.7522M222X370129
HCRL15012150300214.46432471534834222170Tr150X646321261345185M12X1.7522M222X370142
HCRL2006200150285.94288530399549260200Tr170X671491261350215M12X1.7522M260X379145
HCRL2008200200285.95718707469669260200Tr170X671491261350215M12X1.7522M260X379168
HCRL20010200250285.97147884519769260200Tr170X671491261350215M12X1.7522M260X379184
HCRL20012200300285.985771060569869260200Tr170X671491261350215M12X1.7522M260X379200
HCRL2506250150351.95278530416566290220Tr190X671491601555245M12X1.7522M290X385190
HCRL2508250200351.97037707491691290220Tr190X671491601555245M12X1.7522M290X385224
HCRL25010250250351.98796884541791290220Tr190X671491601555245M12X1.7522M290X385244
HCRL25012250300351.9105561060591891290220Tr190X671491601555245M12X1.7522M290X385265
HCRL3006300150424.16362530421571315240Tr210X671491601555260M16X225M315X394230
HCRL3008300200424.18482707496696315240Tr210X671491601555260M16X225M315X394269
HCRL30010300250424.110603884546796315240Tr210X671491601555260M16X225M315X394294
HCRL30012300300424.1127231060596896315240Tr210X671491601555260M16X225M315X394319
