Description
Model: 30SWT
Series: SWT
Product Lines: Industrial Tools
- 70Mpa Max working pressure and the accuracy keep within ±3%
- Altogether 11 models with the range from 303N.m to 180000N.m, which covers the most bolt size
- Small dimensions and compact design for confined spaces
- An integrated pressure relief valve ensures a safer working environment
- Generously sized oil channels in the device, provide minimal heating under continuous load
- Various inserts are available as an accessories, for flexible working
Think Safety
Manufacturer’s rating of load and stroke are maximum safe limits. Good practice encourages using only 80% of these ratings!
Torque Wrench Specifications
Torque Wrench Model Number | 30SWT |
Torque Range(Nm) | 3000-30000 |
Bolt Size(s) | 100-115 |
Drive Unit Weight(Kg) | 11.5 |
Working Head Weight(Kg) | 15.8 |
Torque Wrench Dimensions
Torque Wrench Drive Unit & Cassette Series Specification
Drive Unit Model | Minimum Torque(N.m) | Max. Torque(N.m) | Hexagon Range(mm) | Power Head Weight (Kg) | Work Head Weight (Kg) | A(mm) | B(mm) | C(mm) | E(mm) | F(mm) |
---|---|---|---|---|---|---|---|---|---|---|
3SWT | 203 | 2030 | 19-41 | 1.2 | 1.3 | 148 | 109 | 28 | 40 | 57 |
303 | 3030 | 46-60 | 1.4 | 148 | 109 | 28 | 40 | 57 | ||
6SWT | 560 | 5600 | 41-65 | 2.2 | 1.5 | 168 | 127 | 35 | 50 | 83 |
660 | 6600 | 70-80 | 1.7 | 168 | 127 | 35 | 50 | 83 | ||
10SWT | 986 | 9860 | 41-65 | 3.3 | 3.4 | 216 | 148 | 46 | 66 | 86 |
1200 | 12000 | 70-95 | 3.8 | 216 | 148 | 46 | 66 | 86 | ||
20SWT | 1850 | 18500 | 70-95 | 5.5 | 5.8 | 282 | 191 | 56 | 82 | 86 |
2000 | 20000 | 100-115 | 6.8 | 282 | 191 | 56 | 82 | 86 | ||
30SWT | 3000 | 30000 | 100-115 | 11.5 | 15.8 | 341 | 237 | 72 | 105 | 116 |
40SWT | 4000 | 40000 | 115-135 | 12.5 | 16.8 | 341 | 237 | 72 | 105 | 116 |
4509 | 45090 | 135-155 | 17.5 | 341 | 237 | 72 | 105 | 116 | ||
60SWT | 6000 | 60000 | 115-165 | 13.8 | 18.9 | 374 | 265 | 88 | 130 | 131 |
70SWT | 7000 | 70000 | 130-180 | 30 | 32 | 365 | 278 | 91.8 | 135 | 149 |
90SWT | 9000 | 90000 | 145-210 | 36.8 | 41.6 | 382 | 275 | 102 | 150 | 174 |
130SWT | 13000 | 130000 | 160-230 | 42.5 | 45.6 | 431 | 299 | 119 | 175 | 190 |
160SWT | 16000 | 16000 | 185-255 | 66 | 72 | 482 | 415 | 142.8 | 210 | 205 |
180SWT | 18000 | 180000 | 200-285 | 95.5 | 102 | 550 | 440 | 160 | 235 | 218 |
Cassette Model | R | G | Cassette Model | R | G | Cassette Model | R | G | Cassette Model | R | G | Cassette Model | R | G | Cassette Model | R | G |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
3TS-19 | 27 | 16 | 6TS-34 | 36 | 16 | 10TS-41 | 46 | 22 | 20TS-50 | 60 | 31 | 30TS65 | 66 | 28 | 40TS-85 | 78 | 28 |
3TS-22 | 27 | 14 | 6TS-36 | 36 | 15 | 10TS-46 | 46 | 19 | 20TS-55 | 60 | 28 | 30TS70 | 66 | 26 | 40TS-90 | 78 | 28 |
3TS-27 | 27 | 11 | 6TS-41 | 39 | 15 | 10TS-50 | 46 | 17 | 20TS-60 | 60 | 25 | 30TS75 | 69 | 26 | 40TS-95 | 83 | 28 |
3TS-30 | 29 | 12 | 6TS-46 | 42 | 15 | 10TS-55 | 50 | 18 | 20TS-65 | 60 | 22 | 30TS80 | 69 | 23 | 40TS-100 | 83 | 25 |
3TS-32 | 29 | 11 | 6TS-50 | 44 | 15 | 10TS-60 | 52 | 17 | 20TS-70 | 60 | 19 | 30TS85 | 74 | 25 | 40TS-105 | 89 | 28 |
3TS-34 | 31 | 11 | 6TS-55 | 46 | 14 | 10TS-65 | 55 | 17 | 20TS-75 | 63 | 19 | 30TS90 | 74 | 22 | 40TS-110 | 89 | 25 |
3TS-36 | 31 | 10 | 6TS-60 | 50 | 15 | 10TS-70 | 58 | 17 | 20TS-80 | 66 | 19 | 30TS95 | 78 | 23 | 40TS-115 | 95 | 28 |
3TS-41 | 34 | 10 | 6TS-65 | 53 | 15 | 10TS-75 | 60 | 17 | 20TS-85 | 69 | 19 | 30TS100 | 78 | 20 | 40TS-117 | 95 | 27 |
3TS-46 | 37 | 10 | 6TS-70 | 56 | 15 | 10TS-80 | 63 | 16 | 20TS-90 | 72 | 20 | 30TS105 | 83 | 22 | 40TS-120 | 95 | 25 |
3TS-50 | 40 | 11 | 6TS-75 | 59 | 15 | 10TS-85 | 66 | 16 | 20TS-95 | 74 | 19 | 30TS110 | 83 | 20 | 40TS-125 | 101 | 29 |
3TS-55 | 43 | 11 | 6TS-80 | 61 | 15 | 10TS-90 | 69 | 17 | 20TS-100 | 77 | 19 | 30TS115 | 89 | 23 | 40TS-130 | 101 | 26 |
3TS-60 | 46 | 11 | 10TS-95 | 71 | 16 | 20TS-105 | 80 | 19 | 30TS117 | 89 | 21 | 40TS-135 | 104 | 26 | |||
10TS-100 | 75 | 17 | 20TS-110 | 83 | 19 | 30TS120 | 95 | 26 | 40TS-140 | 110 | 29 | ||||||
10TS-105 | 78 | 17 | 20TS-115 | 87 | 20 | 30TS125 | 95 | 23 | 40TS-145 | 110 | 26 | ||||||
20TS-117 | 87 | 19 | 30TS130 | 99 | 24 | 40TS-150 | 116 | 29 | |||||||||
30TS135 | 99 | 21 | 40TS-155 | 116 | 26 | ||||||||||||
40TS-160 | 128 | 36 | |||||||||||||||
40TS-165 | 128 | 33 | |||||||||||||||
40TS-170 | 128 | 30 | |||||||||||||||
40TS-175 | 128 | 27 |
