Description
Model: NSH6575
Series: NSH
Product Lines: Industrial Tools
- Quick and easy cutting tip replacement
- Drop-tested revolving anchor point and safety lanyard
- Revolving composite handle for vibration and shock isolation
- Nut Splitters include a set of hexagon keys and the following spare parts:
- – cutting tip
- – tip retention screw
- – spare alignment screw
- Standard Safety Lanyard with each nut splitter. Includes steel cable with carabiners.
- 3/8NPT-18 female half coupler is standard
- The maximum allowable hardness to split is ASTM A194 Gr 2H. Not to be used on square nuts or stainless steel.
Think Safety
Manufacturer’s rating of load and stroke are maximum safe limits. Good practice encourages using only 80% of these ratings!
Specifications
Max Cutting Force/Ton | 50 |
Oil Capacity/cm3 | 328 |
Bolt Range | M42-M48 |
Hexagon Nut Range/mm | 65-75 |
Replacement Blade No. | NSH6575CTK |
Weight (kg) | 24.5 |
Dimensions
Dimension A/mm | 396 |
Dimension B/mm | 345 |
Dimension C/mm | 220 |
Dimension D/mm | 202 |
Dimension H/mm | 54 |
Dimension N/mm | 27 |
Dimension S/mm | 61 |
Dimension T/mm | 65 |
Dimension W/mm | 135 |
Series Comparison
Model | Max Cutting Force/Ton | Oil Capacity/cm3 | Bolt Range | Hexagon Nut Range/mm | Replacement Blade No. | Weight/Kg | Dimension A/mm | Dimension B/mm | Dimension C/mm | Dimension D/mm | Dimension H/mm | Dimension N/mm | Dimension S/mm | Dimension T/mm | Dimension W/mm |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
NSC1927 | 12 | * | M12-M18 | 19-27 | NSH1927CTK | 5.8 | 353 | * | 152 | 81 | 18 | 11.5 | 24.5 | 26.5 | 53.5 |
NSC2432 | 15 | * | M16-M22 | 24-32 | NSH2432CTK | 6.3 | 370 | * | 152 | 81 | 25 | 9 | 26.6 | 32 | 57.5 |
NSH1927 | 12 | 46 | M12-M18 | 19-27 | NSH1927CTK | 3.5 | 258 | 213 | 152 | 81 | 18 | 11.5 | 24.5 | 26.5 | 53.5 |
NSH2432 | 15 | 46 | M16-M22 | 24-32 | NSH2432CTK | 4 | 265 | 220 | 152 | 81 | 25 | 9 | 26.5 | 32 | 57.5 |
NSH3646 | 20 | 80 | M24-M30 | 36-46 | NSH3646CTK | 6.9 | 290 | 239 | 169 | 93 | 34 | 16 | 39 | 44 | 83.5 |
NSH5065 | 36 | 230 | M33-M42 | 50-65 | NSH5065CTK | 10.9 | 377 | 322 | 210 | 185 | 45 | 23 | 49.5 | 52 | 108 |
NSH6575 | 50 | 328 | M42-M48 | 65-75 | NSH6575CTK | 24.5 | 396 | 345 | 220 | 202 | 54 | 27 | 61 | 65 | 135 |
