Description
Model: 30SGT
Series: SGT
Product Lines: Industrial Tools
- 70Mpa Max working pressure and the accuracy keep within ±3%;
- Small dimensions and compact design for confined spaces;
- An integrated pressure relief valve ensures a safer working environment;
- Generously sized oil channels in the device, provide minimal heating under continuous load;
- Various inserts are available as an accessories, for flexible working;
- Unique notch design, suitable for working conditions with small clearances such as blowout preventers, Christmas trees, valves, etc;
Think Safety
Manufacturer’s rating of load and stroke are maximum safe limits. Good practice encourages using only 80% of these ratings!
Torque Wrench Specifications
Torque Wrench Model Number | 30SGT |
Torque Range(Nm) | 3000-30000 |
Bolt Size(s) | 100-115 |
Drive Unit Weight(Kg) | 11.5 |
Working Head Weight(Kg) | 15.8 |
Torque Wrench Dimensions
Torque Wrench Drive Unit & Cassette Series Specification
Drive Unit Model | Minimum Torque(N.m) | Max. Torque(N.m) | Hexagon Range(mm) | Power Head Weight (Kg) | Work Head Weight (Kg) | A(mm) | B(mm) | C(mm) | E(mm) | F(mm) |
---|---|---|---|---|---|---|---|---|---|---|
3SGT | 203 | 2030 | 19-41 | 1.2 | 1.3 | 148 | 109 | 28 | 40 | 57 |
303 | 3030 | 46-60 | 1.4 | 148 | 109 | 28 | 40 | 57 | ||
6SGT | 560 | 5600 | 41-65 | 2.2 | 1.5 | 168 | 127 | 35 | 50 | 83 |
660 | 6600 | 70-80 | 1.7 | 168 | 127 | 35 | 50 | 83 | ||
10SGT | 986 | 9860 | 41-65 | 3.3 | 3.4 | 216 | 148 | 46 | 66 | 86 |
1200 | 12000 | 70-95 | 3.8 | 216 | 148 | 46 | 66 | 86 | ||
20SGT | 1850 | 18500 | 70-95 | 5.5 | 5.8 | 282 | 191 | 56 | 82 | 86 |
2000 | 20000 | 100-115 | 6.8 | 282 | 191 | 56 | 82 | 86 | ||
30SGT | 3000 | 30000 | 100-115 | 11.5 | 15.8 | 341 | 237 | 72 | 105 | 116 |
40SGT | 4000 | 40000 | 115-135 | 12.5 | 16.8 | 341 | 237 | 72 | 105 | 116 |
4509 | 45090 | 135-155 | 17.5 | 341 | 237 | 72 | 105 | 116 | ||
60SGT | 6000 | 60000 | 115-165 | 13.8 | 18.9 | 374 | 265 | 88 | 130 | 131 |
70SGT | 7000 | 70000 | 130-180 | 30 | 32 | 365 | 278 | 91.8 | 135 | 149 |
90SGT | 9000 | 90000 | 145-210 | 36.8 | 41.6 | 382 | 275 | 102 | 150 | 174 |
Cassette Model | R | G | Cassette Model | R | G | Cassette Model | R | G | Cassette Model | R | G | Cassette Model | R | G | Cassette Model | R | G |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
3SG-19 | 24 | 13 | 6SG-34 | 33 | 13 | 10SG-41 | 42 | 18 | 20SG-50 | 56 | 27 | 30SG–65 | 60 | 22 | 40SG-85 | 72 | 22 |
3SG-22 | 24 | 11 | 6SG-36 | 33 | 12 | 10SG-46 | 42 | 15 | 20SG-55 | 56 | 24 | 30SG–70 | 60 | 20 | 40SG-90 | 72 | 22 |
3SG-27 | 24 | 8 | 6SG-41 | 36 | 12 | 10SG-50 | 42 | 13 | 20SG-60 | 56 | 21 | 30SG–75 | 63 | 20 | 40SG-95 | 77 | 22 |
3SG-30 | 26 | 9 | 6SG-46 | 39 | 12 | 10SG-55 | 46 | 14 | 20SG-65 | 56 | 18 | 30SG–80 | 63 | 17 | 40SG-100 | 77 | 19 |
3SG-32 | 26 | 8 | 6SG-50 | 41 | 12 | 10SG-60 | 48 | 13 | 20SG-70 | 56 | 15 | 30SG–85 | 68 | 19 | 40SG-105 | 83 | 22 |
3SG-34 | 28 | 8 | 6SG-55 | 43 | 11 | 10SG-65 | 51 | 13 | 20SG-75 | 59 | 15 | 30SG–90 | 68 | 16 | 40SG-110 | 83 | 19 |
3SG-36 | 28 | 7 | 6SG-60 | 47 | 12 | 10SG-70 | 54 | 13 | 20SG-80 | 62 | 15 | 30SG–95 | 72 | 17 | 40SG-115 | 89 | 22 |
3SG-41 | 31 | 7 | 6SG-65 | 50 | 12 | 10SG-75 | 56 | 13 | 20SG-85 | 65 | 15 | 30SG–100 | 72 | 14 | 40SG-117 | 89 | 21 |
3SG-46 | 34 | 7 | 6SG-70 | 53 | 12 | 10SG-80 | 59 | 12 | 20SG-90 | 68 | 16 | 30SG–105 | 77 | 16 | 40SG-120 | 89 | 19 |
3SG-50 | 37 | 8 | 6SG-75 | 56 | 12 | 10SG-85 | 62 | 12 | 20SG-95 | 70 | 15 | 30SG–110 | 77 | 14 | 40SG-125 | 95 | 23 |
3SG-55 | 40 | 8 | 6SG-80 | 58 | 12 | 10SG-90 | 65 | 13 | 20SG-100 | 73 | 15 | 30SG–115 | 83 | 17 | 40SG-130 | 95 | 20 |
3SG-60 | 43 | 8 | 10SG-95 | 67 | 12 | 20SG-105 | 76 | 15 | 30SG–117 | 83 | 15 | 40SG-135 | 98 | 20 | |||
10SG-100 | 71 | 13 | 20SG-110 | 79 | 15 | 30SG–120 | 89 | 20 | 40SG-140 | 104 | 23 | ||||||
10SG-105 | 74 | 13 | 20SG-115 | 83 | 16 | 30SG–125 | 89 | 17 | 40SG-145 | 104 | 20 | ||||||
20SG-117 | 83 | 15 | 30SG–130 | 93 | 18 | 40SG-150 | 110 | 23 | |||||||||
30SG–135 | 93 | 15 | 40SG-155 | 110 | 20 | ||||||||||||
40SG-160 | 122 | 30 | |||||||||||||||
40SG-165 | 122 | 27 | |||||||||||||||
40SG-170 | 122 | 24 | |||||||||||||||
40SG-175 | 122 | 21 |
