Description
Model: EP-213
Product Lines: Industrial Tools
- ‘Safety Cage’ jaw retention system
- Roll threaded shafts for less effort when applying high torque
- More efficient pulling, as one man can do the job where manual pullers often require two operators
- Slim tapered jaws for better gripping in tight spots
- Available in 2 and 3 jaw design
Think Safety
Manufacturer’s rating of load and stroke are maximum safe limits. Good practice encourages using only 80% of these ratings!
Specifications
Maximum Operating Pressure (bar) | 700 |
Capacity(Ton) | 25 |
Number of Jaws | 2 |
Max Reach(mm) | 304 |
Min. Spread(mm) | 63 |
Max. Spread(mm) | 457 |
Center Bolt Dia(mm) | 29 |
Weight(Kg) | 17.2 |
Series Comparison
Model | Capacity(Ton) | Number of Jaws | Max Reach(mm) | Min. Spread(mm) | Max. Spread(mm) | Center Bolt Dia(mm) | Weight(Kg) |
---|---|---|---|---|---|---|---|
EP-204 | 2 | 2 | 101 | 12 | 127 | 14 | 1.4 |
EP-104 | 5 | 3 | 101 | 12 | 127 | 14 | 1.8 |
EP-206 | 6 | 2 | 152 | 12 | 178 | 16 | 3.2 |
EP-106 | 10 | 3 | 152 | 12 | 178 | 16 | 3.6 |
EP-208 | 12 | 2 | 203 | 19 | 304 | 20 | 5.4 |
EP-108 | 17 | 3 | 203 | 19 | 304 | 20 | 6.4 |
EP-210 | 14 | 2 | 245 | 25 | 381 | 20 | 5.9 |
EP-110 | 20 | 3 | 245 | 25 | 381 | 20 | 7.3 |
EP-213 | 25 | 2 | 304 | 63 | 457 | 29 | 17.2 |
EP-113 | 30 | 3 | 304 | 63 | 457 | 29 | 20 |
EP-216 | 35 | 2 | 355 | 76 | 635 | 31 | 25.8 |
EP-116 | 40 | 3 | 355 | 76 | 635 | 31 | 30.8 |
