Description
Model: SWi2025TE
Series: SWI
Product Lines: Industrial Tools
- Practical, portable, and lightweight
- Revolving handle to aid horizontal or vertical spreading
- Removable handle for improved access
- No finger pinch-point
- Increased step-depth on upper steps
- Safety lanyard – 1,0 m length
- Forged key components for strength and reliability
- Rapid disassembly and assembly
- Narrow jaw teeth – improved tool wear.
Think Safety
Manufacturer’s rating of load and stroke are maximum safe limits. Good practice encourages using only 80% of these ratings!
Specifications
Maximum Operating Pressure (bar) | 700 |
Maximum Spreading Force (ton) | 24 |
Maximum Spread (mm) | 103,5 |
Tip Clearance (mm) | 6 |
Jaw Width(mm) | 60 |
Power Source | Split Hydraulic Power |
Oil Capacity (cm3) | 250 |
Weight (kg) | 15 |
Dimensions
Series Comparison
Model | Capacity/Ton | Maximum Spread/mm | Tip Clearance/mm | Jaw Width/mm | Oil Capacity/cm3 | Power | Weight/Kg |
---|---|---|---|---|---|---|---|
SWi2025TE | 24 | 103,5 | 6 | 60 | 250 | Split Hydraulic Power | 15 |
SWI20/25TI | 24 | 103.5 | 6 | 60 | * | Integral Hydraulic Type | 18.1 |
SW14.5TE | 14.5 | 81 | 6 | * | * | Integral Hydraulic Type | 10 |
